A standard wire of TEX series, TEX-E, is solderable wire of single conductor and triple insulation layers. The layers are organized by heat resistant modified polyester and polyamide.

Structure

Dimensions


Nominal
conductor
diameter
(mm)
Tolerance
(mm)
Typical
overall
diameter
(mm)
Maximum
overall
diameter
(mm)
Maximum
conductor
resistance
(omega/km)
Unit Weight
(kg/km)
0.20
±0.008
0.400
0.417
607.6
0.398
0.21
±0.008
0.410
0.427
549.0
0.431
0.22
±0.008
0.420
0.437
498.4
0.465
0.23
±0.008
0.430
0.447
454.5
0.500
0.24
±0.008
0.440
0.457
416.2
0.537
0.25
±0.008
0.450
0.467
382.5
0.575
0.26
±0.010
0.460
0.477
358.4
0.616
0.27
±0.010
0.470
0.487
331.4
0.656
0.28
±0.010
0.480
0.497
307.3
0.697
0.29
±0.010
0.490
0.507
285.7
0.742
0.30
±0.010
0.500
0.520
262.9
0.786
0.32
±0.010
0.520
0.540
230.3
0.882
0.35
±0.010
0.550
0.570
191.2
1.033
0.37
±0.010
0.570
0.590
170.6
1.143
0.40
±0.010
0.600
0.625
145.3
1.316
0.45
±0.010
0.650
0.675
114.2
1.633
0.50
±0.010
0.700
0.725
91.43
1.985
0.55
±0.020
0.750
0.775
78.15
2.371
0.60
±0.020
0.800
0.825
65.26
2.793
0.65
±0.020
0.850
0.875
55.31
3.249
0.70
±0.020
0.900
0.925
47.47
3.741
0.75
±0.020
0.950
0.975
41.19
4.267
0.80
±0.020
1.000
1.030
36.08
4.829
0.85
±0.020
1.050
1.080
31.87
5.425
0.90
±0.020
1.100
1.130
28.35
6.056
0.95
±0.020
1.150
1.180
25.38
6.721
1.00
±0.030
1.200
1.230
23.33
7.422

(Reference Values)

Note: All the above values are shown just for reference and may differ slightly from batch to batch.
