Oracle Cloud Infrastructureに接続する｜クラウド接続の設定｜設定例｜ルータ・ネットワーク機器

補足・注意点

Oracle Cloud InfrastructureとVPN接続する	ベースコンフィグは
	IPsecのコンフィグは
	静的ルートのコンフィグは
	BGPのコンフィグは

OCI F220/F221設定例

<pre>
!
crypto ipsec policy ${ipsecPolicy}
 set pfs group5
 set security-association transform-keysize aes 256 256 256
 set security-association transform esp-aes esp-sha-hmac
exit
!
crypto ipsec selector ${selector}
 src 1 ipv4 any
 dst 1 ipv4 any
exit
!
crypto isakmp keepalive
!
crypto isakmp policy ${isakmpPolicy}
 authentication pre-share
 encryption aes
 encryption-keysize aes 256 256 256
 group 5
 hash sha
exit
!
crypto isakmp profile ${isakmpProfile1}
 local-address ${cpePublicIpAddress}
 set isakmp-policy ${isakmpPolicy}
 set ipsec-policy ${ipsecPolicy}
 set peer ${vpn-ip1}
 ike-version 1
 local-key ascii ${sharedSecret1}
exit
!
crypto isakmp profile ${isakmpProfile2}
 local-address ${cpePublicIpAddress}
 set isakmp-policy ${isakmpPolicy}
 set ipsec-policy ${ipsecPolicy}
 set peer ${vpn-ip2}
 ike-version 1
 local-key ascii ${sharedSecret2}
exit
!
crypto map ${map1} ipsec-isakmp
 match address ${selector}
 set isakmp-profile ${isakmpProfile1}
exit
!
crypto map ${map2} ipsec-isakmp
 match address ${selector}
 set isakmp-profile ${isakmpProfile2}
exit
!
interface Tunnel ${tunnelNumber1}
 tunnel mode ipsec map ${map1}
 ip address ${customer-interface-ip1}
exit
!
interface Tunnel ${tunnelNumber2}
 tunnel mode ipsec map ${map2}
 ip address ${customer-interface-ip2}
exit
</pre>
