ISDB-T re-transmission for CATV
![All channel type[back up usage] OFDM signal processor unit](images/img_spm4204.jpg)
Application
ISDB-T re-transmission for CATV
| Item | Specifications | |
|---|---|---|
| RF Input section | Input signal | ISDB-T |
| Input channel | CH13 to 62[470 to 770MHz] ,1ch,selectable | |
| Input level | Typical 60dBµV[50 to 75dBµV] | |
| Input connecter | F[75Ω] | |
| RF Output section | Output signal | ISDB-T |
| Number of output channel | CH1 to 62[90 to 770MHz] ,1ch,selectable | |
| Output level | 85 to 100dBµV | |
| Output connecter | F[75Ω] | |
| Power Supply/ Others |
Power Supply | DC+24V [from sub-rack : FH-MF-1011A] |
| Dimensions | SP:44.5[W]×400.0[D]×288.0[H]mm Joint unit:44.5[W]×45.5[D]×278.0[H]mm |
|
| Mass | SP:<3.0kg Joint unit:<0.5kg |
|
| Current Use | <500mA | |
